THREAD DIMENSIONS PART NO. O-RING MPa E,G F TUBE O.D. I1,I2 L1,L2 L3 S1 S2,S4 S3 ACHC-12-10-12OG M12X1.5 M10X1 6 O08.1X1.6 13 28 26.5 11 14 14 31.5 L ACHC-14-12-14OG M14X1.5 M12X1.5 8 O09.3X2.4 15.5 30.5 32 14 17 17 ACHC-16-14-16OG M16X1.5 M14X1.5 10 O11.3X2.4 17 32.5 34 16 19 19 ACHC-18-16-18OG M18X1.5 M16X1.5 12 O13.3X2.4 19 34 36 19 22 22 ACHC-22-18-22OG M22X1.5 M18X1.5 15 O15.3X2.4 22 37 39.5 22 27 24 ACHC-26-22-26OG M26X1.5 M22X1.5 18 O19.3X2.4 25.5 42 43.5 27 32 27 ACHC-30-27-30OG M30X2 M27X2 22 O23.5X3.0 29.5 45.8 50 30 36 32 16 L ACHC-36-33-36OG M36X2 M33X2 28 O29.5X3.0 33.3 49.8 54 36 41 41 ADHD-14-12-14OG M14X1.5 M12X1.5 6 O09.3X2.4 17.5 32.5 32 14 17 17 63 S ADHD-16-14-16OG M16X1.5 M14X1.5 8 O11.3X2.4 18.7 33.7 34 16 19 19 ADHD-18-16-18OG M18X1.5 M16X1.5 10 O13.3X2.4 19.5 36 36 19 22 22 ADHD-20-18-20OG M20X1.5 M18X1.5 12 O15.3X2.4 19.5 36 37 19 24 24 ADHD-24-22-24OG M24X1.5 M22X1.5 16 O19.3X2.4 24 42 37.5 24 30 27 ADHD-30-27-30OG M30X2 M27X2 20 O23.5X3.0 28.3 49.8 50 30 36 32 40 S ADHD-36-33-36OG M36X2 M33X2 25 O29.5X3.0 32.8 56.8 54 36 46 41 ADHD-42OG M42X2 M42X2 30 O38.5X3.0 36.2 62.7 57.2 41 50 50
Metric Le Adjustable Stud
PEHEL Hydraulic Model: PACHC-OG PADHD-OG/PACHC-OG/RN PADHD-OG/RN
QTY:
