THREAD TUBE O.D. DIMENSIONS PART NO. MPa E D1 I1 L1 S1 S2 4C-12 M12×1.5 6 7 14 12 14 31.5
L4C-14 M14×1.5 8 8 15 14 17 4C-16 M16×1.5 10 9 16 17 19 4C-18 M18×1.5 12 10 17 19 22 4C-22 M22×1.5 15 11 18 24 27 4C-26 M26×1.5 18 11.5 19 27 32 4C-30 M30×2 22 13.5 21 32 36 16
L4C-36 M36×2 28 14.5 22 41 41 4C-45 M45×2 35 14.5 25 46 50 4C-52 M52×2 42 16 27 55 60 4D-14 M14×1.5 6 11 18 14 17 63
S4D-16 M16×1.5 8 13 20 17 19 4D-18 M18×1.5 10 12.5 20 19 22 4D-20 M20×1.5 12 14.5 22 22 24 4D-22 M22×1.5 14 16 24 24 27 4D-24 M24×1.5 16 15.5 24 27 30 40
S4D-30 M30×2 20 17.5 28 32 36 4D-36 M36×2 25 20 32 38 46 4D-42 M42×2 30 20.5 34 46 50 4D-52 M52×2 38 23 39 55 60 31.5 S
PLUG
PEHEL Hydraulic Model: P4C P4D/P4C-RN P4D-RN
QTY:
