light tube clamp: Structure: assembly including cover plate, rail nut, clamp body,hexagon bolts
Order code
PTLPG----Light series,polypropylene, inside grooved
PTLPS----Light series,polypropylene, inside smoothPTLNG---Light series, polyamide 6, inside grooved
PTLNS---Light series, polyamide 6, inside smooth
(As required, exchange standard ab-breviation TLPG in column of "order code")
Clamp size mm.O.D. inch.I.D inch.O.D. 2 clamp halves TLPG Welding plate short Weld/screw plate Order code Size Order code Size Order code Size b c d e d e d e f n 0 6
6.4
8
9.5
10
12G1/8 1/4
5/16
3/8PTLPG-006
PTLPG-006.4
PTLPG-008
PTLPG-009.5
PTLPG-010
PTLPG-01228 27 - 13.5 PTL - A0 - 30 PTL - B0 - 58 44 6.5 1 6
6.4
8
9.5
10
12G1/8 1/4
5/16
3/8PTLPG-106
PTLPG-106.4
PTLPG-108
PTLPG-109.5
PTLPG-110
PTLPG-11234 27 20 13.5 PTL - A1 20 36 PTL - B1 20 64 50 6.5 2 12.7
13.5
14
15
16
17.2
18G1/4
G3/81/2
5/8PTLPG-212.7
PTLPG-213.5
PTLPG-214
PTLPG-215
PTLPG-216
PTLPG-217.2
PTLPG-21840 33 26 16.5 PTL - A2 26 42 PTL - B2 26 70 56 6.5 3 19
20
21.3
22
23
25G1/2 3/4
1PTLPG-319
PTLPG-320
PTLPG-321.3
PTLPG-322
PTLPG-323
PTLPG-32548 35 33 17.5 PTL - A3 33 50 PTL - B3 33 78 64 6.5 4 26.9
28
30G3/4 PTLPG-426.9
PTLPG-428
PTLPG-43057 42 40 21 PTL - A4 40 59 PTL - B4 40 87 73 6.5 5 32
33.7
35
38
40
42G1
G11/411/4
11/2PTLPG-532
PTLPG-533.7
PTLPG-535
PTLPG-538
PTLPG-540
PTLPG-54270 58 52 29 PTL - A5 52 72 PTL - B5 52 100 86 6.5 6 44.5
45
48
50
50.8
52
55
57G11/2 13/4
2
21/4PTLPG-644.5
PTLPG-645
PTLPG-648
PTLPG-650
PTLPG-650.8
PTLPG-652
PTLPG-655
PTLPG-65786 66 66 33 PTL - A6 66 88 PTL - B6 66 116 110 6.5
DIN 3015 Light Duty Tube Clamp - Carbon Steel & Green Plastic Body
PEHEL Hydraulic Model: PTLPG
QTY:
Light Pipe Clamp
Outer-hexagon socket screw +clamp body +cover plate +welded base plateBody Color: GreenBody Material: Plastic or NylonAbout the item:
1.DIN 3015 Standard Compliance: Manufactured to strict DIN 3015 standards, ensuring perfect interchangeability and reliable performance for your hydraulic and pneumatic systems.
2. Dual Material Options: Available in high-grade carbon steel for superior strength and stainless steel for excellent corrosion resistance in harsh environments.
3. Versatile Application: This light tube clamp is engineered to securely hold pipes, tubes, and hoses, minimizing vibration and noise in industrial machinery.
4. OEM & Custom Branding: Support for Pehel and OEM branding, allowing you to customize the product to meet specific market demands and build brand recognition.
5.Easy & Secure Installation: Designed for quick assembly and disassembly, the clamp ensures a tight, leak-proof grip while simplifying maintenance in complex hydraulic setups.
