THREAD DIMENSIONS PART NO. E F G A,B,C S1 S2,S3,S4 DJ-04 7/16"X20 7/16"X20 7/16"X20 9.5 11 17 DJ-05 1/2"X20 1/2"X20 1/2"X20 9 14 19 DJ-06 9/16"X18 9/16"X18 9/16"X18 9.5 14 19 DJ-08 3/4"X16 3/4"X16 3/4"X16 10.8 16 24 DJ-10 7/8"X14 7/8"X14 7/8"X14 12 22 27 DJ-12 1.1/16"X12 1.1/16"X12 1.1/16"X12 13 24 32 DJ-16 1.5/16"X12 1.5/16"X12 1.5/16"X12 14 33 41
JIC FEMALE 74° SEATTEE
PEHEL Hydraulic Model: PDJ
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:SAE J514 JIC thread
- 1.Standard SAE J514 JIC female 74° cone seat design delivers leak-tight high-pressure hydraulic connection
- 2.Dual material options: carbon steel & stainless steel JIC flare fitting for different working environments
- 3.Silver zinc plating surface enhances rust resistance of JIC hydraulic connector, extending service life
- 4.Support Pehel brand & OEM customization for all sizes JIC female hydraulic adapters
- 5.Wide industrial application heavy-duty JIC 74° cone seat coupling for machinery hydraulic systems
