PART NO. THREAD SEAL DIMENSIONS E F F A B L S1 1JL-04-10 7/16"X20 M10X1 ZHD-10 14 8 29 17 1JL-04-12 7/16"X20 M12X1.5 ZHD-12 14 12 32.5 17 1JL-06-12 9/16"X18 M12X1.5 ZHD-12 14.1 12 33.5 17 1JL-06-14 9/16"X18 M14X1.5 ZHD-14 14.1 12 32 19 1JL-06-18 9/16"X18 M18X1.5 ZHD-18 14.1 12 35.5 24 1JL-06-22 9/16"X18 M22X1.5 ZHD-22 14.1 14 38 27 1JL-08-16 3/4"X16 M16X1.5 ZHD-16 16.7 12 37 22 1JL-08-18 3/4"X16 M18X1.5 ZHD-18 16.7 12 37.5 24 1JL-08-22 3/4"X16 M22X1.5 ZHD-22 16.7 14 40.5 27 1JL-10-18 7/8"X14 M18X1.5 ZHD-18 19.3 12 40.5 24 1JL-10-22 7/8"X14 M22X1.5 ZHD-22 19.3 14 43 27 1JL-12-22 1.1/16"X12 M22X1.5 ZHD-22 21.9 14 48.5 30 1JL-12-27 1.1/16"X12 M27X2 ZHD-27 21.9 16 49 36 1JL-16-33 1.5/16"X12 M33X2 ZHD-33 23.1 18 56 41
PEHEL/JIC MALE 74° CONE / METRIC MALE WITH BONDED SEAL ADAPTER
PEHEL Hydraulic Model: P1JL
QTY:
JIC MALE 74° CONE / METRIC MALE WITH BONDED SEAL ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: JIC MALE 74° CONE
Thread Type 2: METRIC MALE WITH BONDED SEAL
About the item:
1. Straight adapter connecting JIC systems to metric ports.
2. 74° cone seat ensures a reliable, leak-tight flare-type seal on the JIC end.
3. Bonded seal (ZHD) on the metric end provides a leak-tight seal without thread sealant.
4. Available from 7/16"-20 to 1-5/16"-12, with metric ends from M10x1 to M33x2.
5. Ideal for hydraulic, pneumatic, oil and gas systems needing JIC-to-metric conversion.
