THREAD DIMENSIONS PART NO. E F A B S1 1ST9-02SP G1/8"X28 R1/8"×28 21.8 21 11 1ST9-02-04SP G1/8"X28 R1/4"×19 24.3 25.5 14 1ST9-04SP G1/4"X19 R1/4"X19 29 26 14 1ST9-04-02SP G1/4"X19 R1/8""×28 29 23.5 14 1ST9-04-06SP G1/4"×19 R3/8""X19 30 29 16 1ST9-06SP G3/8"X19 R3/8"×19 31.5 28.5 16 1ST9-06-04SP G3/8"×19 R1/4"×19 31.5 26.5 16 1ST9-06-08SP G3/8"X19 R1/2"x14 36 36 22 1ST9-08SP G1/2"X14 R1/2"X14 38 36 22 1ST9-08-06SP G1/2"X14 R3/8"×19 38 32.5 22 1ST9-08-12SP G1/2"X14 R3/4"×14 41 43.5 27 1ST9-12SP G3/4"X14 R3/4"X14 43 43.5 27 1ST9-12-08SP G3/4"X14 R1/2"X14 43 40.5 27 1ST9-12-16SP G3/4"X14 R1"X11 47 50 33 1ST9-16SP G1"×11 R1"X11 48.5 50 33 1ST9-20SP G1.1/4"X11 R1.1/4"×11 57 59 41 1ST9-24SP G1.1/2"X11 R1.1/2"×11 61 62.5 48 1ST9-32SP G2"×11 R2"×11 73.2 74.2 63
90° Elbow JIC Gas Male 60° Cone/BSPT Male
PEHEL Hydraulic Model: P1ST9-SP
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver zinc plating
Connector Type: 90 degree elbow hydraulic adapter
Thread Type: JIC gas male 60° cone, BSPT male taper thread
- About the item:
- 1.This 90 elbow JIC 60 cone BSPT male fitting uses carbon & stainless steel with silver zinc plating for rust resistance.
- 2.Dual thread design JIC gas male 60° cone + BSPT male taper thread realizes quick cross-standard pipeline conversion.
- 3.Precision CNC machined JIC and BSPT threads, tight fit for zero leakage under high hydraulic pressure.
- 4.90 degree elbow structure saves installation space for JIC BSPT hydraulic connectors in compact equipment layout.
- 5.Pehel brand & full OEM customization available for all sizes JIC 60 cone to BSPT male hydraulic adapters.
