PART NO. THREAD DIMENSIONS E F A B S1 S2 2K9-14 M14X1.5 M14X1.5 28.5 10.5 14 19 2K9-16 M16X1.5 M16X1.5 31.5 10 16 22 2K9-18 M18X1.5 M18X1.5 33.8 11.5 19 24 2K9-22 M22X1.5 M22X1.5 38 14 22 27 2K9-24 M24X1.5 M24X1.5 41.2 15 24 30 2K9-30-24 M30X1.5 M24X1.5 47.5 15 30 30 2K9-30 M30X1.5 M30X1.5 48 18.3 30 36 2K9-33 M33X1.5 M33X1.5 55 21.3 33 41
PEHEL | 90° Metric Male 60° Cone x Metric Female 60° Seat Hydraulic Elbow Adapter
PEHEL Hydraulic Model: 2K9
QTY:
Type: 90° Metric Male 60° Cone / Metric Female 60° Seat Adapter
Angle: 90° Elbow
End 1: Metric Male 60° Cone
End 2: Metric Female 60° Seat
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plated
1.90° elbow adapter featuring a metric male 60° cone end and a metric female 60° seat end, designed for hydraulic systems.
2.Male end has a 60° cone sealing surface that provides metal-to-metal sealing when mated with a corresponding female cone.
3.Female end has a 60° cone seat that receives a matching male cone for reliable sealing.
4.90° body configuration allows directional change of fluid flow in confined spaces.
5.Manufactured from high-strength carbon steel with anti-rust surface treatment for durability.
