PART NO. FLANGE SIZE DIMENSIONS MPa A B d h M N 3000PSI FL-08WM 12" 54 45.6 M8 6.2 38.1 17.5 34.5 FL-12WM 34" 65 51.8 M10 6.2 47.6 22.2 FL-16WM 1" 70 58.4 M10 7.5 52.4 26.2 FL-20WM 1.14" 79 72.6 M10 7.5 58.7 30.2 27.6 FL-24WM 1.12" 94 82.2 M12 7.5 69.9 35.7 20.7 FL-32WM 2" 102 96.4 M12 9 77.8 42.9 FL-40WM 2.12" 114 108.2 M12 9 88.9 50.8 17.2 FL-48WM 3" 135 130.6 M16 9 106.4 61.9 13.8 6000PSI FS-08WM 1/2" 56 47.2 M8 7.2 40.5 18.2 42 FS-12WM 3/4" 71 60 M10 8.2 50.8 23.8 FS-16WM 1" 81 69.9 M12 9 57.2 27.8 FS-20WM 1.14" 95 77.2 M14 9.8 66.6 31.8 FS-24WM 1.12" 113 95 M16 12 79.3 36.5 FS-32WM 2" 133 113.8 M20 12 96.8 44.5
Pehel | PFL-FS-WM | Hydraulic SAE Flange Clamp whit Metric Thread
PEHEL Hydraulic Model: FL-FS-WM
QTY:
China SAE Hydraulic Flange
China SAE Hydraulic Flange Adapters Manufacturers
As one of the leading SAE hydraulic flange adapters manufacturers and suppliers in China, our factory offers SAE Flange L.T. 3000PSI, Interlock SAE Flange L.T., One Piece Fitting SAE Flange, SAE Split Flange Clamp, SAE Flange H.T, SAE 9000PSI CAT Flange, JIS Flange. Please feel free to wholesale custom made SAE hydraulic flange adapters made in China here.Material: Carbon steel
Brand: Pehel
Color: Silver
Thread: Metric
Size: 1/4"-2"
Type: Flange
About the item:
1. Secure flange clamp – designed for quick and reliable flange connections.
2. Precision hose flanges – ensure leak-free sealing in high-pressure systems.
3. Heavy-duty construction – durable materials withstand vibration and shock.
4. Easy assembly – clamp design simplifies installation and maintenance.
5. Versatile compatibility – fits standard SAE and metric flange configurations.
