PART NO. ORING DIMENSIONS FLANGESIZE WELDTUBEO.D D A D1 D2 L 1FSW-12IN 3/4" 3/4" 24.99X3.53 8.9 41.3 31.7 33 1FSW-16IN 1" 1" 32.92X3.53 9.6 47.6 38 37 1FSW-20IN 1.1/4" 1.1/4" 37.69X3.53 10.4 54 43.6 42 1FSW-24IN 1.1/2" 1.1/2" 47.22X3.53 12.7 63.5 50.8 45 1FSW-32IN 2" 2" 56.74X3.53 12.7 79.4 66.5 45
PEHEL | SAE Flange 6000PSI Weld Inch Tube Adapter, High Pressure Hydraulic Weld Flange for Inch Tubing
PEHEL Hydraulic Model: 1FSW-IN
QTY:
Type: SAE Weld Flange Adapter
Pressure Rating: 6000PSI (Code 62)
End 1: SAE Flange (Code 62)
End 2: Inch Weld Tube
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
About the item:
1.SAE flange 6000PSI weld inch tube adapter, designed as a high-pressure hydraulic flange fitting with one end for welding to inch-sized tubing and the other end configured as a SAE 6000PSI (Code 62) flange connection.
2.The flange end conforms to SAE J518 Code 62 standard with four bolt holes for secure mounting to mating flanged components.
3.Weld tube end allows permanent connection to inch-size steel tubing by butt welding.
4.Manufactured from high-strength carbon steel with anti-rust surface treatment for reliable performance in demanding high-pressure hydraulic environments.
5.Precision machined flange face ensures reliable sealing with standard O-ring when mated to corresponding flange port.
