PART NO. THREAD FLANGE SIZE O RING DIMENSIONS E A b D1 D2 L S1 1JFS-12 1.1/16"X12 3/4" 24.99X3.53 21.9 8.9 41.3 31.7 82 30 1JFS-16 1.5/16"X12 1" 32.92X3.53 23.1 9.6 47.6 38 95.5 36 1JFS-16-20 1.5/16"X12 1.1/4" 37.69X3.53 23.1 10.4 54 43.6 95.5 36 1JFS-20 1.5/8"X12 1.1/4" 37.69X3.53 24.3 10.4 54 43.6 97.5 46 1JFS-16-24 1.5/16"X12 1.1/2" 47.22X3.53 23.1 12.7 63.5 50.8 95.5 36 1JFS-20-24 1.5/8"X12 1.1/2" 47.22X3.53 24.3 12.7 63.5 50.8 97.5 46 1JFS-24 1.7/8"X12 1.1/2" 47.22X3.53 27.5 12.7 63.5 50.8 118.5 50 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube. Hydraulic adapter :
1)Material: 45# Carbon Steel
2)Different sizes available
3)Zinc plated
4)ISO9001: 2000
5). Salt Spray Test: > 72 Hours
6). Sample. Please contact our sales person for the free sample.
Quick Details
Delivery Detail: 1-2weeks
Package Detail: Nylon plastic+corrugated carton +Multiple plywood case
Custom-orientated Service: Produce according to your drawings or sample, offer custom-design
JIC Male 74 Cone / SAE Flange 6000PSI
PEHEL Hydraulic Model: 1JFS
QTY:
SAE hydraulic fitting adapters
We are professional jic male 74 cone, SAE Flange 6000PSI manufacturers and suppliers in China, specialized in brass and stainless steel, carbon, steel, stainless steel or copper alloy products. Be free to wholesale bulk custom made jic male 74 cone from our factory.
Standard: DIN Material: Medium Carbon Steel Connection: Male Surface Treatment: Zinc Coating Head Type: Hexagon 74 Cone: 6000psi
