THREAD DIMENSIONS PART NO. E F A B L S1 S2 2NB-02 Z1/8"X27 G1/8"X28 10.5 6 25.5 12 14 2NB-02-04 Z1/8"X27 G1/4"X19 10.5 5 27 14 19 2NB-04-02 Z1/4"X18 G1/8"X28 15 6 30 17 14 2NB-04 Z1/4"X18 G1/4"X19 15 5 31 17 19 2NB-04-06 Z1/4"X18 G3/8^X19 15 6.5 33 17 22 2NB-04-08 Z1/4"X18 G1/2"X14 15 7.8 35 19 27 2NB-06 Z3/8"X18 G3/8"X19 16 6.5 35 19 22 2NB-06-04 Z3/8"X18 G1/4"X19 16 5 33 19 19 2NB-06-08 Z3/8"X18 G1/2"X14 16 7.8 36 19 27 2NB-08 Z1/2"X14 G1/2"X14 19.5 7.8 41 22 27 2NB-08-04 Z1/2"X14 G1/4"X19 19.5 5 38.5 22 19 2NB-08-06 Z1/2"X14 G3/8"X19 19.5 6.5 40.5 22 22 2NB-08-12 Z1/2"X14 G3/4"X14 19.5 10.5 44.5 27 32 2NB-12 Z3/4"X14 G3/4"X14 19.5 10.5 44.5 30 32 2NB-12-06 Z3/4"X14 G3/8"X19 19.5 6.5 41.7 30 22 2NB-12-08 Z3/4"X14 G1/2"X14 19.5 7.8 43.5 30 27 2NB-12-16 Z3/4"X14 G1"X11 19.5 11 46.5 32 41 2NB-16-12 Z1"X11.5 G3/4"X14 25.5 10.5 51.5 36 32 2NB-16 Z1"X11.5 G1"X11 25.5 11 52.5 36 41 2NB-20 Z1.1/4"X11.5 G1.1/4"X11 26.5 11.5 58 46 50 2NB-24 Z1.1/2"X11.5 G1.1/2"X11 27.5 12.5 62 50 55 2NB-32 Z2"X11.5 G2"X11 27.5 17 68 65 70
NPT Male to BSP Female 60° Cone Seat Adapter
PEHEL Hydraulic Model: P2NB
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Straight Adapter
Thread Type: BSP, NPT
Surface Treatment: CR3+ White Zinc Plated
About the item:
1.60° Cone Sealing Tech: Engineered with a precision BSP female 60 cone seat, delivering metal-to-metal contact that outperforms flat-face washers under pressure.
2.Silver Zinc Protection: Advanced silver color zinc plating shields the carbon steel connector from rust, extending service life in humid or outdoor conditions.
3.Dual-Metal Options: Choose rugged carbon steel or premium stainless steel construction to balance budget and chemical resistance in your fluid lines.
4.Pehel OEM Assurance: As a certified Pehel supplier, we provide full OEM customization on cone angle and thread pitch for proprietary machinery.
5.Pehel Strict Tolerance: Strict tolerance crimp stem enables stable hose crimping, avoids hose pull-off & oil seepage.
