THREAD DIMENSIONS PART NO. E F A B L S1 S2 2BJ-02-04 G1/8"X28 7/16"X20 10 9.5 24 14 17 2BJ-02-06 G1/8"X28 9/16"X18 10 9.5 24.5 14 19 2BJ-04 G1/4"X19 7/16"X20 12 9.5 26.5 19 17 2BJ-04-05 G1/4"X19 1/2"X20 12 9 26.5 19 19 2BJ-04-06 G1/4"X19 9/16"X18 12 9.5 27.5 19 19 2BJ-04-08 G1/4"X19 3/4"X16 12 10.8 29 19 24 2BJ-06 G3/8"X19 9/16"X18 13.5 9.5 30.5 22 19 2BJ-06-08 G3/8"X19 3/4"X16 13.5 10.8 32.5 22 24 2BJ-06-10 G3/8"X19 7/8"X14 13.5 12 33 22 27 2BJ-08 G1/2"X14 3/4"X16 16 10.8 37 27 24 2BJ-08-06 G1/2"X14 9/16"X18 16 9.5 35 27 19 2BJ-08-10 G1/2"X14 7/8"Xl4 16 12 37.5 27 27 2BJ-10 G5/8"X14 7/8"X14 17.5 12 38 30 27 2BJ-12 G3/4"X14 1.1/16"X12 18.5 13 42 32 32 2BJ-12-08 G3/4"X14 3/4"X16 18.5 10.8 40 32 24 2BJ-12-10 G3/4"X14 7/8"X14 18.5 12 41 32 27 2BJ-12-16 G3/4"X14 1.5/16"X12 18.5 14 43 32 41 2BJ-16 G1"X11 1.5/16"X12 20.5 14 46 41 41 2BJ-16-20 G1"X11 1.5/8"X12 20.5 15 50 41 50 2BJ-20 G1.1/4"X11 1.5/8"X12 20.5 15 50 50 50 2BJ-20-24 G1.1/4"X11 1.7/8"X12 20.5 19 50 50 55 2BJ-24 G1.1/2"X11 1.7/8"X12 23 19 54.5 55 55 2BJ-32 G2"X11 2.1/2"X12 25.5 23.5 57.5 70 75
PEHEL/BSP MALE DOUBLE USE FOR 60° SEAT OR BONDED SEAL / JIC FEMALE 74°SEAT ADAPTER
PEHEL Hydraulic Model: P2BJ
QTY:
BSP MALE DOUBLE USE FOR 60° SEAT OR BONDED SEAL / JIC FEMALE 74°SEAT ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: MALE BSPP 60 CONE SEAT
Thread Type 2: FEMALE JIC 74 CONE SEAT
ABOUT THE ITEM:
1. P2BJ dual-purpose hydraulic adapter features BSP male thread with dual sealing options (60° cone seat & bonded seal) plus JIC female 74° flare seat (SAE J514), bridges European BSP and American JIC hydraulic piping standards.
2. Complete size range from 2BJ-02 to 2BJ-32 covers all mainstream G thread & UNF JIC specs, standardized A/B/L/S1/S2 dimensions for universal interchange across fluid power equipment.
3. Precision CNC machined carbon steel with zinc electroplated finish delivers outstanding anti-corrosion and vibration resistance, maintains zero-leak metal-to-metal sealing under continuous high-pressure operation.
4. Dual hex flat S1 & S2 wrench surfaces enable easy torque tightening during assembly, effectively prevents thread loosening and hydraulic oil leakage for construction, marine and industrial machinery.
5.Direct factory supply P2BJ BSP to JIC transition fitting with strict thread tolerance inspection, supports bulk wholesale, OEM drawing customization and fast lead time for global hydraulic fitting distributors.
