THREAD DIMENSIONS PART NO. E F A B S1 S2 2B4-04 G1/4"X19 G1/4"X19 20.3 5 14 19 2B4-04-06 G1/4"X19 G3/8"×19 20.3 6.5 14 22 2B4-06 G3/8"X19 G3/8"×19 22 6.5 16 22 2B4-06-04 G3/8"x19 G1/4"X19 22 5 16 19 2B4-08 G1/2"X14 G1/2"X14 27 7.8 22 27 2B4-08-06 G1/2"X14 G3/8"×19 27 6.5 22 22 2B4-10 G5/8"X14 G5/8"X14 28.5 9 22 30 2B4-10-08 G5/8"×14 G1/2"X14 28.5 7.8 22 27 2B4-12 G3/4"X14 G3/4"X14 31 10.5 27 32 2B4-16 G1"X11 G1"X11 35 11 33 41 2B4-20 G1.1/4"×11 G1.1/4"X11 38.5 11.5 41 50 2B4-24 G1.1/2"×11 G1.1/2"X11 44 12.5 48 55 2B4-32 G2"X11 G2"X11 51 17 63 70
Pehel | P2B4 | Hydralic 45°elbow BSP 60 Seat Male to Female Hose Adapters
PEHEL Hydraulic Model: P2B4
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
Connector Type: Elbow
Thread Type: BSPP
About the item:
1. BSPP thread – Uses standard parallel (G) threads for reliable connections
2. 60° cone seal – Provides a leak-tight seal for BSPP hose fittings
3. 45° elbow design – Saves space and routes hoses efficiently in tight areas
4. BSPP hose fittings compatibility – Works with standard BSPP hydraulic hose ends
5. Durable material options – Available in carbon steel, stainless steel, and brass
