PART NO.
THREAD DIMENSIONS E F A B S1 S2 P2TB9-04 R1/4"-19 G1/4"-19 25.5 5.5 14 19 -04-06 R1/4"-19 G3/8"-19 25.5 6.3 14 22 -06-04 R3/8"-19 G1/4"-19 28.5 5.5 16 19 -06 R3/8"-19 G3/8"-19 28.5 6.3 16 22 -06-08 R3/8"-19 G1/2"-14 30.5 7.5 19 27 -08-06 R1/2"-14 G3/8"-19 36 6.3 22 22 -08 R1/2"-14 G1/2"-14 36 7.5 22 27 -08-12 R1/2"-14 G3/4"-14 37.3 10.9 24 32 -08-16 R1/2"-14 G 1"-11 40.8 11.7 30 41 -12-08 R3/4"-14 G1/2"-14 43.5 7.5 27 27 -12 R3/4"-14 G3/4"-14 43.5 10.9 27 32 -12-16 R3/4"-14 G 1"-11 45.3 11.7 30 41 -16-12 R 1"-11 G3/4"-14 50 10.9 33 32 -16 R 1"-11 G 1"-11 50 11.7 33 41 -20 R1.1/4"X11 R1.1/4"X11 59 11 41 50 -24 R1.1/2"X11 R1.1/2"X11 62.5 13 48 55
Pehel / 2TB9 / Hydraulic adapter 90 Degree Elbow BSPT Male to BSP Female
PEHEL Hydraulic Model: P2TB9
QTY:
Hydraulic adaptor 90 Degree Elbow BSPT to BSP Carbon Steel
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: Elbow
Thread: BSP BSPT
About the item:
1. 90° BSPT male to BSP female elbow – ideal for hydraulic line routing.
2. Carbon steel hydraulic adapter delivers high durability and corrosion resistance in demanding systems.
3. Leak-proof BSPT-to-BSP thread conversion ensures secure, reliable connections under high pressure.
4. Compact 90-degree design minimizes stress on hoses and simplifies installation in confined areas.
5. Precision-machined Pehel 2TB9 fitting offers long service life for industrial and mobile hydraulics.
