90°METRIC FEMALE 24° MULTISEAL H.T.

Model: P20591C-T

QTY:

  • You May Also Like

  • PART NO. THREAD E HOSE BORE TUBE O.D. DIMENSIONS
    DN DASH A C H S2
    20591C-18-04T M18X1.5 6 04 10 30 4 38.5 22
    20591C-20-06T M20X1.5 10 06 12 35 5 39 24
    20591C-24-08T M24X1.5 12 08 16 43 4 47 30
    20591C-30-10T M30X2 16 10 20 56.5 7 56.5 36
    20591C-36-12T M36X2 20 12 25 59.5 7 61 46
    20591C-42-16T M42X2 25 16 30 77.7 7 77.5 50
    20591C-52-20T M52X2 32 20 38 93 9 87.5 60
    NOTE:1.For use with braided hoses.                   2.If use with spiral hoses,hose fitting series number is 20592C-XX-XX
